Emerson EPRO A6125 Dual-Channel Piezoelectric Module

Description

The Emerson EPRO A6125 Dual-Channel Piezoelectric Module is designed for high-precision vibration monitoring in industrial machinery. With dual-channel capability, it provides accurate signal conditioning for piezoelectric sensors, ensuring reliable data acquisition in critical rotating equipment applications.

Specifications

• Model Number: A6125

• Product Type: Dual-Channel Piezoelectric Module

• Channels: 2 independent piezoelectric sensor inputs

• Compatibility: Emerson EPRO monitoring systems

• Input Type: Piezoelectric vibration sensors

• Voltage Supply: 24 VDC (system dependent)

• Operating Temperature: -40 °C to +70 °C

• Shock Resistance: 10 g, half-sine wave, 11 ms duration

• Vibration Endurance: 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz)

• Airborne Contaminants: ISA-S71.04-1985, Class G3

• Relative Humidity: 5–95%, non-condensing

• Protection Rating: IP20

Features

• Dual-Channel Monitoring: Supports two piezoelectric sensors for simultaneous vibration measurement

• High Accuracy: Provides precise signal conditioning for critical machinery diagnostics

• Durability: Built to withstand shock, vibration, and airborne contaminants

• System Integration: Seamlessly connects with Emerson EPRO monitoring platforms

• Industrial Grade: Suitable for continuous operation in mission-critical environments
