The Emerson DeltaV S-Series KC3020X1-BA2 Digital Output Card provides 32 channels of high-side switching at 24 VDC, designed for large-scale process control systems requiring robust and efficient output management.
Technical Specifications
Channels: 32 Digital Outputs
Output Type: High-Side Switching, 24 VDC
Local Bus Power: 12 VDC at 150 mA
Bussed Field Power: 30 VDC at 3 A
Field Circuit Capacity: 30 VDC at 1 A per channel, 3 A per card
Operating Temperature: -40°C to +70°C
Shock Resistance: 10 g, ½ sinewave, 11 ms duration
Vibration Endurance:
1 mm peak-to-peak from 2–13.2 Hz
0.7 g from 13.2–150 Hz
Airborne Contaminants Compliance: ISA-S71.04-1985, Class G3
Relative Humidity: 5–95% non-condensing
Terminal Block Key Position: B6
Key Features
High-density 32-channel design for space-efficient control
High-side switching for safe load management
Rugged construction for harsh industrial conditions
Wide operating temperature range ensures field reliability
Seamless integration with Emerson DeltaV S-Series systems
Application Scenarios
This card is ideal for industries requiring extensive digital output control, including:
Petrochemical and refining plants
Power generation and utility systems
Oil & gas automation facilities
Large-scale water treatment operations
FAQ
Q: How does the KC3020X1-BA2 differ from the KJ3202X1-BK1? A: The KC3020X1-BA2 offers 32 channels compared to the 8 channels of the KJ3202X1-BK1, making it suitable for high-density applications.
Q: What is the maximum load per channel? A: Each channel supports up to 1 A at 30 VDC, with a total of 3 A per card.
Q: Is this card suitable for environments with airborne contaminants? A: Yes, it complies with ISA-S71.04-1985 Class G3 standards, ensuring durability in contaminated environments.
