BMXCPS2000 | Schneider Modicon X80 | Power Supply Module

Product Description

 BMXCPS2000 The Schneider Electric Modicon X80 BMXCPS2000 power supply module delivers stable and reliable energy distribution for automation systems. Designed to support multiple voltage outputs, it ensures consistent operation of processors, I/O modules, and sensors in demanding industrial environments.

Technical Specifications

General Information

• Product Series: Modicon X80

• Type: Power Supply Module

• Backplane Compatibility: Not compatible with BMEXBP..02

• Primary Voltage: 100–240 V AC

• Secondary Power Outputs:

  • 10.8 W at 24 V DC (sensor supply)

  • 16.8 W at 24 V DC (I/O modules and processor)

  • 8.3 W at 3.3 V DC (logic supply)

Electrical Characteristics

• Primary Voltage Range: 85–264 V

• Frequency: 50/60 Hz

• Frequency Limits: 47–63 Hz

• Apparent Power: 0.07 kVA

• Input Current: 0.31 A at 240 V, 0.61 A at 115 V

• Inrush Current: 30 A at 120 V, 60 A at 240 V

• I²t on Activation: 12 A²·s at 240 V

• It on Activation: 0.06 A·s at 240 V, 0.03 A·s at 120 V

Protection & Reliability

• MTBF: 4,638,000 hours

• Protection Types:

  • Internal fuse (primary circuit, non-accessible)

  • Overload, overvoltage, and short-circuit protection (secondary circuit)

• Secondary Current Ratings:

  • 0.45 A at 24 V DC (sensor supply)

  • 0.7 A at 24 V DC (I/O modules and processor)

  • 2.5 A at 3.3 V DC (logic supply)

• Max Power Dissipation: 8.5 W

Control & Indicators

• Status LEDs:

  • Green LED (rack voltage OK)

  • Green LED (sensor voltage)

• Control Type: RESET push-button (cold restart)

• Connections:

  • 2-pin alarm relay connector

  • 5-pin connector (line supply, protective earth, 24 V DC sensor input)

Insulation & Safety

• Insulation Resistance: ≥ 100 MΩ (primary/ground, primary/secondary)

• Dielectric Strength:

  • 1500 V (primary/secondary I/O logic supply)

  • 1500 V (primary/secondary I/O power supply and processor)

  • 2300 V (primary/secondary sensor supply)

  • 1500 V (primary/ground)

  • 500 V (24 V sensor output/ground)

Environmental Conditions

• Operating Temperature: 0–60 °C

• Storage Temperature: -40–85 °C

• Humidity: 5–95% at 55 °C (non-condensing)

• Altitude: 0–2000 m; 2000–5000 m with derating

• Vibration Resistance: 3 gn

• Shock Resistance: 30 gn

• Protection Rating: IP20

• Microbreak Immunity: 1 ms

Certifications & Standards

• Directives: 2014/35/EU (Low Voltage), 2014/30/EU (EMC)

• Protective Treatment: TC

• Certifications: CE, UL, CSA, EAC, RCM, Merchant Navy

Application Scenarios

• Reliable power distribution for Modicon X80 automation racks

• Industrial environments requiring stable multi-voltage outputs

• Systems with high reliability demands and extended MTBF

FAQ

Q: Can BMXCPS2000 be used with BMEXBP..02 backplanes? A: No, it is not compatible with BMEXBP..02.

Q: What protection features are included? A: Overload, overvoltage, and short-circuit protection for secondary circuits, plus an internal fuse for the primary circuit.

Q: How does BMXCPS2000 compare to BMXCPS3500? A: BMXCPS2000 provides lower output power, making it suitable for smaller systems, while BMXCPS3500 supports higher loads for larger installations.
