Bently Nevada Proximitor Sensor | 330180-X2-05

Engineering Purpose

The 330180-X2-05 is a high-performance signal conditioner for the 3300 XL proximity transducer system. It generates an RF signal to drive a probe and translates the return impedance into a linear voltage. This "Multiple Approvals" version is specifically engineered for critical machinery protection—such as steam turbines and compressors—operating in global hazardous environments.

Technical Data Summary

• Component Type: 3300 XL Proximitor Sensor

• Part Number: 330180-X2-05

• Probe Compatibility: 3300-series 5 mm and 3300 XL 8 mm probes

• Measurement Type: Static (position) & Dynamic (vibration/speed)

• Frequency Response: 0 Hz to 10 kHz

• Scale Factor: 7.87 V/mm (200 mV/mil)

• Weight: 0.24 kg (0.54 lbs)

• Mounting: High-density Panel or DIN-rail

Decoding the Model Configuration

• 330180: Bently Nevada 3300 XL Proximitor series base platform.

• X2: Mounting & System Length Option. This variable specifies the combination of system length (e.g., 5.0m or 9.0m) and the specific mounting hardware (typically a panel-mount or DIN-rail adapter).

• 05: Agency Approval Option. Multiple Approvals version, carrying global certifications (ATEX, IECEx, CSA, etc.) for installation in international hazardous zones.
