Bently Nevada 990-08-XX-01-00 Vibration Transmitter

Engineering Purpose

The 990-08-XX-01-00 is a 2-wire, loop-powered vibration transmitter designed for robust machinery monitoring. It integrates the functionality of a proximitor and a signal conditioner, providing a 4-20 mA output proportional to radial vibration. This model is specifically scaled for a 0-8 mils range, making it suitable for larger vibration envelopes typically found in motors, pumps, and mid-sized turbines.

Technical Data Summary

• Component Type: 2-Wire Vibration Transmitter

• System Compatibility: 3300 NSv Proximity Probe

• Part Number: 990-08-XX-01-00

• Full-Scale Range: 0-8 mils pp (0-200 µm pp)

• System Length: Configurable (XX = 50 for 5.0m or 70 for 7.0m)

• Mounting Type: 35 mm DIN rail clips (01)

• Agency Approval: Not required / Standard (00)

• Frequency Response: 5 Hz to 6,000 Hz ($\pm$0.3 dB)

• Power Supply: 12 to 35 Vdc input

Decoding the Model Configuration

• 990: Bently Nevada 990 series vibration transmitter.

• 08: 0-8 mils peak-to-peak full-scale measurement range.

• XX: System Length Option. (Configured as 50 for 5.0m or 70 for 7.0m total system length).

• 01: Equipped with 35 mm DIN rail clips for quick cabinet installation.

• 00: Standard version for non-hazardous or Zone 2 / Div 2 locations without specific extra certifications.
