Bently Nevada 9200-09-01-01-00 velocity transducer

Engineering Purpose

The 9200-09-01-01-00 is a specialized low-frequency velocity transducer designed for monitoring absolute vibration on large, slow-speed rotating machinery. With a high sensitivity of 20 mV/mm/s, it captures the subtle mechanical energy of long-period vibration, making it essential for predictive maintenance on equipment operating as low as 30 RPM (0.5 Hz).

Technical Data Summary

• Component Type: Low-Frequency Velocity Seismoprobe

• Part Number: 9200-09-01-01-00

• Sensitivity: 20 mV/mm/s (500 mV/in/s)

• Frequency Range: 0.5 Hz to 4.5 Hz (270 cpm)

• Connectivity: Two-wire system

• Mounting: Circular M10x1 metric thread

• Weight: 2.0 kg (4.4 lbs)

• Certification: CE Certified

Decoding the Model Configuration

• 9200: Bently Nevada 9200 series seismic velocity transducer platform.

• 09: Sensitivity Option. Specifically tuned for low-frequency detection at 20 mV/mm/s.

• 01: Mounting Option. Features a circular base with a metric M10 x 1 threaded stud.

• 01: Connector/Cable Option. Standard industrial connector configuration for 2-wire signal transmission.

• 00: Agency Approval. Standard version for general industrial/non-hazardous environments.
