Bently Nevada 86739-01 Vibration Monitor

Product Overview

The Bently Nevada 86739-01 is a dual-channel vibration monitor for the 3500 Series system. It provides real-time machinery protection by processing signals from proximity probes and velocity transducers. Fully API 670 compliant, it features programmable alarm thresholds and buffered diagnostic outputs.

Technical Specifications

• Model Number: 86739-01

• System Family: Bently Nevada 3500 Series

• Module Type: Dual Vibration Monitor (2 Channels)

• Supported Inputs: Proximity probes, velocity transducers

• Measurement Types: Radial, axial, and casing vibration

• Outputs: * 4-20 mA proportional outputs

• High (Alert) and Danger (Trip) level alarm relays

• Buffered transducer signals (Front ports)

• Compliance: API 670 Machinery Protection Systems

• Operating Temperature: -35°C to +65°C

• Mounting: 3500 System Rack-mounted

Key Features and Engineering Advantages

• High-Density Monitoring: Two independent channels in a single slot maximize rack usage without sacrificing the individual configuration flexibility of each vibration loop.

• API 670 Compliance: Fully meets the American Petroleum Institute's standards for machinery protection, ensuring the highest level of reliability for critical plant assets.

• Buffered Diagnostics: Integrated front-panel buffered outputs allow for detailed diagnostic "deep dives" using portable analyzers without the risk of accidentally tripping the machine.

• Programmable Protection: Supports highly customizable alarm setpoints for both "Alert" (maintenance warning) and "Danger" (automatic shutdown) levels.

• Universal Input Support: Compatible with both eddy-current proximity probes and seismic velocity transducers, making it adaptable to a wide range of machinery types.
