Bently Nevada 82368-01 3-Wire RTD Input Module

Product Overview

The Bently Nevada 82368-01 is a high-precision input module for the 3300/35 Six-Channel Temperature Monitor. It provides independent monitoring for six channels using a 3-wire RTD configuration to compensate for lead-wire resistance.

Technical Specifications

• Part Number: 82368-01.

• Manufacturer: GE / Bently Nevada.

• Product Family: 3300/35 Six-Channel Temperature Monitor.

• Input Configuration: 3-Wire RTD.

• Number of Channels: 6 Independent Channels.

• Mounting: Rear-rack I/O slot.

• Compatibility: Fully integrated with Bently Nevada 3300 series racks.

• Condition: Industrial-grade, high-durability construction.

Key Features and Engineering Advantages

• Six-Channel Capacity: Monitors up to six separate temperature points within a single rack slot, providing high-density data acquisition for complex machinery trains.

• 3-Wire Lead Compensation: Utilizes the 3-wire bridge technique to compensate for the resistance of the field wiring, ensuring more accurate readings than standard 2-wire setups.

• Real-Time Supervision: Enables continuous on-line monitoring, allowing the 3300/35 system to trigger immediate "Alert" or "Danger" alarms to prevent equipment overheating.

• Rugged Termination: Features heavy-duty screw terminals that provide secure electrical contact, even in environments subject to constant industrial vibration.

• Maintenance Efficiency: The modular PCB design allows for straightforward replacement or troubleshooting within the 3300 rack architecture.
