Bently Nevada 79748-01 Relay Output Record Terminal Module

Quick Overview

The 79748-01 is a Relay Output Record Terminal Module designed to handle the critical "handshake" between monitoring racks and external control systems. It provides the physical electrical termination for alarm, shutdown, and trip signals. This module ensures that when a vibration threshold is breached, the command to alert operators or trip the machine is transmitted with 100% reliability.

Technical Data

• Model: 79748-01

• Module Type: Relay Output / Terminal Block

• Compatibility: Bently Nevada 3300 and 3500 series racks

• Relay Type: Dry-contact (Form C: NO/NC options)

• Operating Temp: -35 °C to +65 °C

• Installation: Modular rack-mount slot

Key Features

• Failsafe Termination: Provides secure connection points for trip logic, ensuring that machinery protection signals are never lost due to poor wiring.

• Seamless Integration: Purpose-built for the Bently Nevada ecosystem, allowing for quick expansion of alarm capabilities in existing 3300 or 3500 racks.

• Rugged Design: Built to endure the high-interference and vibration-prone environments of industrial control rooms and local equipment sheds.

• Flexible Wiring: Features screw-type or plug-in terminals that simplify field installation and long-term maintenance.

• Modular Maintenance: The slot-based design allows technicians to replace or service the module without disturbing adjacent monitoring cards.
