The79532-01is a criticalKeyphasor® System Monitordesigned to provide power and signal conditioning for up to four transducers. It acts as the synchronization heart of a monitoring rack, delivering precise timing signals used to calculate machine speed and phase. This module is essential for advanced diagnostics, such as identifying the specific location of a mechanical imbalance on a rotating shaft.
Technical Data
Input Voltage:24 VDC
Output Signal:4-20 mA
Frequency Range:10 Hz to 1 kHz
Operating Temp:-40°C to +85°C
Sensitivity:100 mV/g (Conditioned signal)
Weight:1.56 kg
Housing:Stainless Steel / Industrial Grade
Key Features
Quad-Channel Conditioning:Simultaneously powers and processes signals from four independent Keyphasor® transducers.
Front-Panel BNC Access:Features integrated BNC connectors for quick, local access to conditioned signals without disturbing permanent wiring.
Intelligent Alarm Management:Includes local setpoint adjustment and a parallel reset function that can be triggered locally or remotely.
System Safeguards:Features "Power-Up Inhibit" to prevent false trips during startup and "Trip Multiply" for temporary bypass during specific machine states.
Status Visibility:Equipped with clear LED indicators for Rack Inhibit and Trip Multiply status, ensuring operators always know the system's operational state.
