Bently Nevada 330930-045-00-CN | Extension Cable Assembly

Product Overview

The 330930-045-00-CN functions as a high-frequency signal bridge within the 3300 XL NSv proximity system. It effectively extends the transmission path between the proximity probe and the Proximitor sensor, ensuring that raw displacement signals remain unattenuated over longer distances. This component is critical for plants requiring remote mounting of signal conditioning electronics without compromising the sub-micron accuracy required for monitoring small-diameter machinery.

Technical Data Summary

• Component Type: Extension Cable Assembly

• System Series: 3300 XL NSv

• Part Number: 330930-045-00-CN

• Total Length: 4.5 meters (14.8 feet)

• Connectivity: Miniature Coaxial ClickLoc

• Cable Shielding: Standard (Unarmored)

• Operating Environment: -51°C to +177°C

• Regional Standards: China Compliance (CN)

• Impedance: 50 $\Omega$ (nominal)

• Material: Ruggedized FEP jacket

Decoding the Model Configuration

The internal architecture of the 330930-045-00-CN is defined by specific manufacturing suffixes:

• 330930: Identifies the NSv-specific extension cable series.

• 045: Defines the physical length as 4.5 meters, calibrated for system signal matching.

• 00: Specifies the connector style as standard unarmored ClickLoc interface.

• CN: Denotes mandatory regulatory certification for deployment within the Chinese industrial market.
