Bently Nevada 330907-05-30-05-02-CN Transducer System

Technical Overview

The 330907-05-30-05-02-CN is a high-precision proximity probe engineered for the 3300 XL NSv (Near-field) series. This transducer is specifically designed to overcome the limitations of standard proximity probes when monitoring small-diameter shafts or targets where traditional magnetic fields are too large to detect sub-micron displacement accurately. It provides reliable, non-contact vibration and radial position measurements, ensuring critical insight into the health of small rotating machinery components.

Detailed Technical Specifications

• System Series: 3300 XL NSv Proximity Transducer System

• Probe Model: 330907-05-30-05-02-CN

• Unthreaded Case Length: 5 mm

• Overall Case Length: 30 mm

• Total Cable Length: 0.5 meters

• Connector Type: Miniature Coaxial ClickLoc connector

• Standard Agency Approval: CN (China compliance)

• Linear Range: 1.0 mm (40 mils)

• Operating Temperature: -51°C to +177°C

• Storage Temperature: -51°C to +177°C

• Probe Tip Material: Polyphenylene Sulfide (PPS)

• Housing Material: AISI 303 Stainless Steel

Model Configuration Breakdown

The part number 330907-05-30-05-02-CN provides specific configuration details:

• 330907: Indicates the 3300 XL NSv Proximity Probe.

• 05: Specifies an unthreaded length of 5 mm.

• 30: Defines the total physical case length as 30 mm.

• 05: Represents a total cable length of 0.5 meters.

• 02: Indicates the connector/cable configuration (Miniature Coaxial ClickLoc connector, armor included).

• CN: Denotes the specific regulatory compliance for the Chinese market.
