Bently Nevada 330130-080-00-05 Extension Cable

Product Overview

The 330130-080-00-05 is a precision-engineered extension cable for the Bently Nevada 3300 XL 8mm proximity system. It provides a stable capacitive link between the probe and Proximitor sensor, utilizing high-grade FEP insulation to ensure linear signal transmission and robust EMI resistance. This module is essential for capturing accurate vibration and displacement data in high-speed rotating machinery located in hazardous industrial zones.

Detailed Technical Specifications

The 330130-080-00-05 is built to the following professional specifications:

• System Compatibility: 3300 XL 8mm Proximity Transducer System

• Cable Length: 8.0 meters (approx. 26.2 feet)

• Jacket Material: Fluorinated Ethylene Propylene (FEP)

• Connector Construction: Gold-plated miniature coaxial connectors

• Impedance: 75 $\Omega$ (system matched)

• Operating Temperature: -51 °C to +177 °C (-60 °F to +350 °F)

• Minimum Bend Radius: 25.4 mm (1.0 inch)

• Hazardous Area Rating: Multiple Approvals (ATEX, IECEx, CSA)

Configuration Matrix (Model Breakdown)

The nomenclature of the 330130-080-00-05 defines its specific hardware configuration:

• Cable Length Option (-080): Indicates an 8.0 meter length. Typically utilized in 9-meter systems when paired with a 1.0-meter probe, providing significant reach for remote sensor mounting.

• Connector Protector Option (-00): Specifies No Connector Protectors. This configuration is ideal for installations within tight conduits or junction boxes where space is at a premium.

• Agency Approval Option (-05): Represents Multiple Approvals. This confirms the cable is certified for use in intrinsically safe applications and explosive atmospheres globally.
