The Bently Nevada 330130-040-01-00 is a high-performance 8mm proximity probe designed for non-contacting displacement and vibration measurements. It acts as a critical interface for the 3300 XL monitoring system, providing precise shaft motion data to prevent mechanical failure and ensure the operational integrity of high-speed rotating assets.
Technical Specifications
Probe Tip Diameter:8 mm
Mounting Thread:3/8-24 UNF-2A
Unthreaded Length:4.0 inches
Overall Case Length:4.1 inches
Total Cable Length:1.0 Meter (3.3 feet)
Connector Type:Miniature coaxial ClickLoc
Agency Approval:No specific approvals required (Standard)
Linear Range:2.0 mm (80 mils)
Typical Applications
This specific configuration, featuring a long unthreaded reach and a standard 1.0-meter cable, is ideal for the following industrial scenarios:
Deep Bore Mounting:The 4.0-inch unthreaded length allows for monitoring through thick machine walls or bearing housings without thread interference.
Large Turbomachinery:Measuring radial vibration and axial position in utility-scale steam and gas turbines.
Petrochemical Equipment:Providing continuous condition monitoring for centrifugal compressors and multi-stage pumps.
Diagnostic Data Acquisition:Acting as a Keyphasor sensor to provide phase reference and speed data for machinery analysis.
