Bently Nevada 330104-00-06-10-01-05 3300 Proximity Probe

Product Overview

The 330104-00-06-10-01-05 is a high-precision eddy current sensor designed for non-contacting vibration and displacement monitoring. It converts the mechanical gap between the probe tip and a rotating shaft into a proportional voltage signal, providing critical data for the early detection of machinery faults in high-speed rotating assets.

Technical Specifications

• Brand: Bently Nevada

• Model Number: 330104-00-06-10-01-05

• Probe Diameter: 8 mm

• Mounting Thread: M10 x 1 (Metric)

• Unthreaded Length: 0 mm (Option 00)

• Overall Case Length: 60 mm (Option 06)

• Total Cable Length: 1.0 meter / 3.3 feet (Option 10)

• Connector Type: Miniature coaxial ClickLoc™ connector (Option 01)

• Agency Approval: Multiple approvals (Option 05)

• Linear Range: 2 mm (80 mils)

• Sensitivity: 7.87 V/mm (200 mV/mil)

• Operating Temperature: -35°C to +177°C (-31°F to +350°F)

• Housing Material: AISI 303 or 304 Stainless Steel (SST)

Typical Applications

• Radial Vibration Monitoring: Continuous tracking of shaft oscillation in steam turbines, gas turbines, and centrifugal compressors.

• Axial Position Detection: Measuring thrust shaft movement to prevent rotor-to-stator contact and machinery damage.

• Keyphasor® Reference: Providing precision timing pulses for phase angle measurements and rotational speed tracking.

• Machinery Protection: Integrated into API 670 compliant protection systems, such as the Bently Nevada 3500 series racks.
