Bently Nevada 330104-00-04-10-02-00 current sensor

Product Overview

The 330104-00-04-10-02-00 is designed for high-precision industrial sensing, offering full compliance with API 670 standards for machinery protection. Built with a polyphenylene sulfide (PPS) tip and a stainless steel housing, this probe is resilient against harsh lubricants and high-pressure environments. The integrated Viton® O-ring ensures a robust pressure seal between the tip and case, while the ClickLoc™ connector provides a secure, vibration-resistant electrical link, ensuring stable signal transmission for automated control systems.

Technical Specifications

• Brand: Bently Nevada

• Model Number: 330104-00-04-10-02-00

• Series: 3300 XL 8 mm

• Probe Tip Diameter: 8 mm

• Unthreaded Length: 0 mm (Option 00)

• Overall Case Length: 40 mm (Option 04)

• Total Cable Length: 1.0 meter / 3.3 feet (Option 10)

• Connector Type: Miniature coaxial ClickLoc™ connector (Option 02)

• Tip Material: Polyphenylene sulfide (PPS)

• Case Material: AISI 303 or 304 Stainless Steel (SST)

• Sealing: Viton® O-ring for differential pressure resistance

• Standard Compliance: API 670 for machinery protection systems

• Interchangeability: Fully compatible with 3300 XL extension cables and Proximitor sensors

Typical Applications

• Radial Vibration Analysis: Detecting shaft instability or imbalance in high-speed compressors and steam turbines.

• Axial Position Monitoring: Measuring thrust movement to safeguard against internal rotor contact.

• Keyphasor® Reference: Generating once-per-turn pulses for RPM tracking and phase-related diagnostics.

• Machinery Protection: Serving as a primary sensor input for 3500 series monitoring racks in power generation and oil & gas facilities.
