Bently Nevada 3300 XL NSv | 330980-50-05

• Quick Overview

  The 330980-50-05 is a specialized signal conditioner for the NSv (Narrow Side-view) transducer system. It is specifically designed for small-diameter shafts (under 50 mm) or confined spaces where standard probes would experience "side-view" interference. This sensor is the industrial standard for centrifugal air compressors and aero-derivative turbines.

  Technical Data

  • System Type: 3300 XL NSv (Narrow Side-view)

  • Scale Factor: 7.87 V/mm (200 mV/mil)

  • System Length: 5.0 meters (16.4 feet)

  • Mounting: Panel mount

  • Approvals: Multiple Approvals (ATEX, IECEx, CSA)

  • Operating Temp: Up to +95°C (+203°F)

  Key Features

  • Narrow Side-View: Uses a focused magnetic field to allow installation in tight radial clearances without signal corruption.

  • Compact Integration: Designed for high-density placement in machinery protection racks or local junction boxes.

  • Global Certification: The 05 option carries international hazardous area approvals, suitable for global oil, gas, and power projects.

  • Robust Output: Provides high-resolution voltage proportional to displacement, supporting both vibration and thrust position analysis.

  • SpringLoc Terminals: Features screwless terminal strips for fast, vibration-resistant field wiring.

  System Type: 3300 XL 11 mm

• Scale Factor: 3.94 V/mm (100 mV/mil)

• System Length: 9.0 meters (29.5 feet)

• Mounting: 35 mm DIN-rail

• Approvals: Multiple Approvals (ATEX, IECEx, CSA)

• Power: -24 VDC nominal

Key Features

• Extended Range: Specifically tuned for 11 mm probes to provide a ~4 mm linear window.

• Interchangeable: Replace probes or cables without individual bench calibration.

• ClickLoc Connectors: Gold-plated connectors that lock securely with a "click" to resist vibration.

• SpringLoc Terminals: Fast, screwless wiring that ensures a gas-tight, vibration-proof connection.

• High Immunity: Superior RFI/EMI protection for reliable data in noisy power plant environments.
