Bently Nevada 3300 NSv Proximitor | 330980-50-00

Engineering Purpose

The 330980-50-00 is a specialized proximity signal conditioner designed for the 3300 NSv (Narrow Side view) transducer system. This system is engineered for use in confined spaces or on small-diameter shafts where a standard 8 mm or 11 mm probe is too large. The NSv Proximitor processes the high-frequency signal from an NSv probe to measure vibration and position on machines like small centrifugal compressors and aircraft derivative turbines.

Technical Data Summary

• Component Type: 3300 NSv Proximitor Sensor

• Part Number: 330980-50-00

• System Length: 5.0 meters (16.4 feet)

• Scale Factor: 7.87 V/mm (200 mV/mil)

• Mounting: Panel mount

• Power Requirement: -17.5 Vdc to -26 Vdc

• Operating Temperature: -35°C to +85°C

• Shipping Weight: 1.5 kg

Decoding the Model Configuration

• 330980: Bently Nevada 3300 NSv (Narrow Side view) Proximitor series.

• 50: Total Length and Mounting Option. Factory-calibrated for a 5.0-meter system length and configured for panel mounting.

• 00: Agency Approval Option. Standard configuration; not required for hazardous area use.
