The Bently Nevada 3300/10-01-01-00-00 is a dedicated power supply module engineered for the 3300 Monitoring System. This rack-mounted unit serves as the primary power source for all installed monitoring modules, providing regulated DC voltage necessary for the accurate measurement of vibration, thrust, eccentricity, expansion, and tachometer signals. By ensuring a stable and clean power environment, this module maintains the integrity of the entire 3300 rack configuration.
Features
Provides regulated DC output to support diverse monitoring modules within the 3300 system.
Includes integrated rack-wide OK status monitoring to signal power supply health.
Designed specifically for the 3300 system architecture, ensuring seamless integration.
Supports standard 115/230 VAC input configurations.
Applications
This power supply module is a critical component for industrial machinery protection systems. It is widely utilized in rotating equipment monitoring, including steam turbines, gas turbines, compressors, and large motors, where continuous, high-reliability data acquisition is mandatory for site safety and operational efficiency.
Technical Specifications
Model
3300/10-01-01-00-00
Brand
Bently Nevada
Series
3300
Product Type
Power Supply Module
Operating Temperature
0 to 60 degC
Total Rack Capacity
Approx. 150 W
Input Voltage
115/230 VAC
Installation Guidelines
Ensure the 3300 rack is completely de-energized before inserting or removing the power supply module.
Verify that the input voltage matches the configured setting of the module to prevent damage.
Ensure proper seating in the rack backplane to maintain firm electrical contact.
Maintain adequate ventilation around the rack to adhere to the 0 to 60 degC operating temperature range.
Handle with standard ESD precautions to prevent damage to internal electronic components.
FAQ
What is the primary function of the 3300/10 module?
The 3300/10 module converts incoming AC power into the regulated DC voltages required by the various monitoring modules housed within the Bently Nevada 3300 rack.
Can this module be used in any 3300 rack?
Yes, the 3300/10 is the standard power supply module for the 3300 series. Please verify your specific rack configuration and power requirements against the 01-01-00-00 ordering suffix to ensure compatibility with your site's power infrastructure.
Does this module provide status diagnostics?
Yes, the module features an OK relay output that monitors the health of the power supply, allowing the system to alert operators if power levels deviate from established parameters.
