Bently Nevada 3300/16-12-01-02-03-02-00 Radial Vibration

Product Overview

The Bently Nevada 3300/16-12-01-02-03-02-00 is a precision dual-channel monitor engineered for continuous machinery protection. As part of the 3300 Series, it is specifically designed to measure radial vibration and shaft position (gap).

Technical Specifications

• Model Number: 3300/16-12-01-02-03-02-00.

• Type: XY/Gap Dual Vibration Monitor.

• Measurement Channels: 2 (Independent).

• Input Compatibility: Proximitor® sensors.

• Frequency Range: 0 to 100 kHz.

• Accuracy: ±0.5 dB.

• Response Time: < 1 second.

• Power Supply: 120V AC.

• Communication: RS485 Interface.

• Operating Temp: 0°C to +65°C (+32°F to +150°F).

• Dimensions: 240 mm × 480 mm × 100 mm.

Key Features and Engineering Advantages

• Dual Measurement Logic: Capable of monitoring both vibration (dynamic) and gap (static) simultaneously, allowing operators to see both the "shake" of the shaft and its physical position within the bearing.

• API 670 Compliance: Meets the stringent requirements of the American Petroleum Institute for machinery protection, ensuring the highest level of safety and reliability for oil and gas applications.

• Fast Fault Detection: With a response time of less than one second, the 3300/16 can trigger emergency trips before a vibration event leads to catastrophic mechanical failure.

• Modular Architecture: Easily integrates into the standard 3300 rack system, allowing for simple hot-swapping and maintenance without de-energizing the entire monitoring suite.

• Independent Alarm Logic: Each channel features its own set of Alert and Danger setpoints, which can be configured for latching or non-latching operation depending on the facility's safety protocols.
