The Bently Nevada 3300/61 is a dual-channel monitor designed for velocity measurement and vibration analysis within the 3300 monitoring system. This module provides continuous monitoring of machinery vibration, offering reliable data for predictive maintenance and protection of rotating equipment. It is engineered to integrate seamlessly into standard 3300 monitor chassis configurations.
Features
Dual-channel configuration for independent velocity monitoring.
Provides proportional 4-20 mA output signals for integration with external control systems or data loggers.
Designed for compatibility with the Bently Nevada 3300 series rack and chassis architecture.
Robust environmental specifications suitable for industrial plant floor conditions.
Technical Specifications
Model Number
3300/61-03-01-01-00-00-00
Monitor Type
Dual Vector Monitor / Dual Velocity Monitor
Power Supply
-24 VDC
Power Consumption
10-20 Watts
Outputs
4-20 mA
Operating Temperature
-30 degC to +65 degC
Storage Temperature
-40 degC to +85 degC
Relative Humidity
0-95% RH (non-condensing)
Installation Guidelines
Ensure the 3300 chassis is properly grounded before installing the module.
Always power down the rack or remove the power supply before inserting or removing the monitor module to prevent electrical damage.
Verify that the module is fully seated in the chassis slot and that the front panel connectors are secured.
Use shielded cabling for all I/O connections to minimize electromagnetic interference (EMI) in high-noise industrial environments.
Ensure adequate ventilation around the 3300 chassis to maintain operating temperatures within the specified range.
FAQ
What is the primary function of the 3300/61 monitor?
The 3300/61 is a dual-channel velocity monitor used to measure and track vibration levels on rotating machinery, providing critical data for machine health monitoring.
Is this module compatible with other 3300 series components?
Yes, this monitor is designed specifically for the Bently Nevada 3300 series monitor chassis and is compatible with standard 3300 system components.
What type of output does this module provide?
The module provides 4-20 mA output signals, which are standard for transmitting vibration data to PLCs, DCS, or other plant-wide monitoring systems.
