Bently Nevada 200200-03-03-05 Condition Monitoring Module

Quick Overview

The 200200-03-03-05 is a specialized Condition Monitoring Module belonging to the 200 Series ProTIM-R (Programmable Transducer Interface Module) family. Engineered specifically for use with the Trendmaster® Pro distributed monitoring system, this module acts as a localized data acquisition point for machinery health. It is optimized for temperature monitoring, featuring configurable options for 2-wire or 3-wire Platinum RTD (Resistance Temperature Detector) channels.

Technical Data

• Part Number: 200200-03-03-05

• Series: 200 Series ProTIM-R

• Input Compatibility: 2-wire or 3-wire Pt RTD (Resistance Temperature Detectors)

• Mounting: Standard 35mm DIN rail

• Weight: 0.35 kg (0.77 lbs)

• System Integration: Trendmaster Pro Distributed Architecture

• Network Communication: Digital bus interface for daisy-chaining multiple modules

Key Features

• Distributed Monitoring Intelligence: Part of a scalable architecture that allows hundreds of sensor points to be monitored over a single cable run, ideal for large-scale plants with numerous small-to-mid-sized rotating assets.

• Flexible RTD Configuration: Supports both 2-wire and 3-wire RTD setups, allowing users to balance installation simplicity with the high-accuracy lead-wire compensation offered by 3-wire sensors.

• Simplified DIN Rail Installation: The compact, rail-mounted design allows the module to be installed in small local junction boxes near the equipment, protecting it from harsh environmental conditions.

• Machinery Protection Synergy: While primarily used for condition monitoring and trending, it provides the essential thermal data required to identify bearing overheating or cooling system failures before they lead to downtime.

• Industrial Hardening: Built to operate in the demanding electrical and thermal environments of factory floors, petrochemical plants, and power generation facilities.

• Legacy Reliability: As a established component of the 200 Series, it offers a proven track record for long-term stability and consistent data reporting in 24/7 industrial operations.
