TheBently Nevada 200200-02-02-CNis a high-performanceDual-Input ProTIM-R Modulewithin theTrendmaster® Profamily. It is specifically engineered to provide a cost-effective, distributed solution for monitoring rotating machinery.
Compatible Sensors:Accelerometers, Velocity Sensors, RTDs, and Thermocouples
Signal Processing:Acceleration Enveloping (AE) and Velocity Integration (A-V)
Current Range:+4 mA to +20 mA (OK range > +3.2 mA)
Voltage Range:+1 Vdc to +5 Vdc (OK range > 0.8 Vdc)
Frequency Response:DC to 3 kHz
Resolution:±1% of full-scale value (typical)
Voltage Measurement Range:0 to 50 mV
Isolation:Electrical isolation for temperature inputs
Mounting:Standard DIN rail mountable
Key Features & Engineering Advantages
Distributed Intelligence:As a ProTIM-R (Programmable Transducer Interface Module), it processes raw signals locally. This allows for complex analytics likeAcceleration Enveloping, which is vital for detecting early-stage bearing and gearbox faults.
Versatile Sensor Support:Whether your asset requires high-frequency vibration monitoring via accelerometers or thermal tracking via RTDs, this module handles both, reducing the variety of spare parts needed on-site.
Trendmaster® Pro Integration:Designed to plug directly into the Trendmaster digital network, it allows thousands of points to be monitored across a plant using a single cable run, drastically lowering wiring costs.
Robust Signal Integrity:The module features strict "OK Range" monitoring for both current and voltage. If a sensor wire breaks or shorts, the module immediately flags the data as invalid, preventing false alarms.
Isolated Thermal Inputs:Electrical isolation for temperature channels protects the wider communication network from ground loops and electrical noise common in industrial motor housings.
