Bently Nevada 185410-01 Ranger Pro Gateway

Quick Overview

The 185410-01 is the Ranger Pro Wireless Gateway, the central nervous system of the Bently Nevada wireless condition monitoring ecosystem. This device acts as the bridge between the field-mounted ISA100.11a wireless sensors (like the Ranger Pro 134M0389) and the plant’s wired control and monitoring networks.

Technical Data

• Model Number: 185410-01

• Product Type: Ranger Pro Wireless Gateway

• Wireless Protocol: ISA100.11a

• Wired Communication: Ethernet (Modbus TCP, HART-IP, HTTPS)

• Frequency Band: 2.4 GHz ISM

• Network Capacity: Supports up to 50–100 devices (topology dependent)

• Power Supply: 12–30 VDC

• Environmental Rating: IP66/IP67 (Weatherproof)

• Operating Temp: -40°C to +70°C (-40°F to +158°F)

• Certifications: ATEX/IECEx Zone 2, North American Div 2

Key Features

• Industrial Mesh Management: Automatically manages the ISA100.11a network, handling device joining, security keys, and path optimization to ensure 99.9% data reliability in complex industrial environments.

• Seamless System Integration: Converts raw wireless data into standard Modbus registers, allowing for easy mapping into existing plant SCADA or DCS systems without proprietary software.

• Secure Data Pipeline: Utilizes 128-bit AES encryption and dual-layer authentication, ensuring that machinery health data remains protected from unauthorized access.

• Rugged Infrastructure: Designed for direct outdoor installation. The IP67 housing and wide temperature range eliminate the need for expensive climate-controlled enclosures.

• High-Gain Communication: Equipped with a high-performance external antenna port to maximize the line-of-sight range between the gateway and remote sensors or repeaters.

• Built-in Web Interface: Features an intuitive browser-based management tool for network configuration, sensor diagnostics, and health monitoring of the wireless signal quality.

• Model Number: 16699-10-02-01

• Measurement Principle: Piezoelectric Velocity Transducer

• Frequency Range: 10 Hz to 1,000 Hz

• Sensitivity: 4.0 V/in/sec ±10%

• Output: Voltage proportional to vibration velocity

• Operating Temp: -35°C to +120°C

• Cable Length: 10 m (33 ft)

• Weight: 0.5 kg

• Housing Material: Industrial-grade Stainless Steel

Key Features

• Extended 10m Cable: The generous 33-foot integrated cable provides maximum flexibility for routing through cable trays and large machine skids without the need for immediate intermediate connectors.

• High-Accuracy Diagnostics: Optimized to detect the most common mechanical faults, including unbalance, shaft misalignment, and structural looseness, by providing a clean, high-amplitude signal.

• Rugged Stainless Steel Housing: The sensor is encased in a heavy-duty stainless steel shell, protecting the internal piezoelectric elements from the corrosive chemicals and physical impacts found in heavy manufacturing.

• Thermal Endurance: Engineered to operate reliably at temperatures up to +120°C, allowing for permanent installation on hot machine casings in power generation and petrochemical facilities.

• Simplified Integration: Designed for direct "plug-and-play" compatibility with Bently Nevada 3500 series monitoring racks and other standard industrial velocity interface modules.
