Bently Nevada 149787-01 Trendmaster DSM Input Card

Product Overview

The Bently Nevada 149787-01 is a specialized TIM (Transducer Interface Module) Line Input Card designed for use within the Trendmaster DSM (Dynamic Scanning Module) system. Its primary role is to serve as the interface between the central monitoring unit and the field-mounted sensors.

Technical Specifications

• Part Number: 149787-01

• System Compatibility: Trendmaster DSM

• Category: PLC Add-On Board / PC Board

• Function: TIM Line Input Interface

• Application Support: RBO TIMs, PV TIMs, and SPA Line integration

• Weight: 0.35 lbs (Approx. 0.16 kg)

• Hardware Interface: Multi-pin rack-mount connector

• Status: Discontinued by Manufacturer (Available as a legacy/spare part)

Key Features & Engineering Advantages

• Scalable Monitoring: The 149787-01 is essential for large-scale "Balance of Plant" monitoring, enabling the DSM system to manage high-density sensor networks through a single line interface.

• Versatile Variable Tracking: It supports both standard process variables (PV) and relay board options (RBO), allowing the system to monitor vibration, temperature, and status contacts simultaneously.

• Distributed Architecture: By interfacing with SPA lines, this card reduces the total amount of copper wiring required in a facility, as multiple TIMs can share a single communication trunk back to the input card.

• Optimized Signal Processing: Designed specifically for the Trendmaster protocol, the card ensures high-speed data scanning without signal degradation over long cable runs.

• Compact Form Factor: Its lightweight, slim PC board design allows for high-density installation within DSM racks, maximizing the use of cabinet space.
