Bently Nevada 149356-01 Display Router Box Module

Product Overview

The 149356-01 Display Router Box Module is a key component in the Bently Nevada 3500/94M Display System, enabling operators to view machinery protection data on external monitors. It is used in conjunction with the 3500/94M VGA Display and provides routing, signal conditioning, and system interface functions.

Key Specifications

• Manufacturer: Bently Nevada (GE)

• Part Number: 149356-01

• Product Type: Display Router Box Module

• System Compatibility: 3500/94M Display Monitor

• Function: Routes display signals from monitoring racks to external VGA monitors

• Features:

  • Standard color VGA monitor support

  • Touch-screen technology

  • OK and Bypass LED indicators

  • Mounting up to 8 meters from the rack

• Weight: ~5 lbs (2.27 kg)

• Condition: Available new and refurbished

• Warranty: Typically 1-year

Functional Highlights

• Signal Routing: Connects the 3500 rack monitoring system to external displays.

• Operator Interface: Provides real-time visualization of machinery protection data.

• Flexibility: Can be mounted away from the rack for convenient operator access.

• Diagnostics: LED indicators show system health and bypass status.

Application Scenarios

• Power generation plants monitoring turbines and generators

• Petrochemical facilities requiring real-time machinery diagnostics

• Heavy industry applications with centralized monitoring racks

• Situations where operators need remote or extended display access

FAQ

Q: What display type does the 149356-01 support? A: It supports standard VGA monitors with touch-screen capability.

Q: How far can the module be mounted from the rack? A: Up to 8 meters.

Q: What indicators are included? A: OK and Bypass LEDs for quick system diagnostics.
