Bently Nevada 140482-02 Vibration Interface Module

Quick Overview

The 140482-02 is a high-performance 4-Channel Vibration Monitoring Module designed for the Bently Nevada 3500 Machinery Protection System. This module acts as a versatile interface for various vibration sensors, including proximity probes and velocity transducers.

Technical Data

• Model Number: 140482-02

• Number of Channels: 4 Independent Channels

• Sensor Compatibility: Proximity Probes, Velocity Transducers

• Input Signal Range: ±10 V

• Output Signal Range: 0 to 10 V

• Operating Temp: -40°C to +85°C

• Storage Temp: -55°C to +105°C

• Humidity: 0 to 95% non-condensing

• Vibration Resistance: 20 g peak, 10 to 2000 Hz

Key Features

• Multi-Sensor Interface: Seamlessly supports both proximity and velocity inputs, allowing for simultaneous monitoring of shaft displacement and absolute casing vibration.

• External Termination Design: Optimized for field wiring through external termination blocks, offering greater flexibility for complex cabinet configurations and easier maintenance.

• User-Programmable Filters: Features customizable frequency response settings, enabling engineers to tune the module to the specific mechanical frequencies of their machinery.

• Industrial Hardening: Engineered for extreme reliability with a wide operating temperature range and high vibration tolerance (up to 20 g peak).

• Comprehensive Monitoring: Delivers continuous high-resolution data to the 3500 system, ensuring rapid identification of mechanical unbalance, misalignment, or bearing defects.
