Bently Nevada 134M2166-01 Predictive Maintenance

Product Overview

The Bently Nevada 134M2166-01 is a high-performance single-axis wireless vibration sensor part of the Ranger Pro family. Engineered for continuous monitoring of rotating assets, it utilizes the ISA100.11a wireless protocol to securely transmit data to Bently Nevada’s System 1 software.

Technical Specifications

• Model Number: 134M2166-01.

• Series: Ranger Pro.

• Measurement Axis: Single-axis vibration.

• Frequency Range: Up to 10 kHz.

• Wireless Protocol: ISA100.11a (IEC 62734).

• Battery: Replaceable D-size lithium-thionyl chloride.

• Battery Life: Up to 5 years (configuration dependent).

• Operating Temp: -40°C to +85°C.

• Ingress Protection: IP67.

• Software Integration: Bently Nevada System 1.

Key Features and Engineering Advantages

• Optimized Single-Axis Monitoring: Specifically designed for applications where monitoring a single primary axis of vibration is sufficient for fault detection, reducing data overhead while maintaining safety.

• Reliable ISA100.11a Connectivity: Operates on a dedicated industrial wireless mesh network, ensuring high data reliability and security compared to standard consumer-grade wireless protocols.

• Extended Battery Life: Powered by a heavy-duty D-size lithium battery, minimizing the "total cost of ownership" by reducing the frequency of technician visits for battery replacements.

• High-Frequency Capture: Capable of capturing data up to 10 kHz, allowing for the early detection of bearing defects and gear mesh issues that occur at higher frequencies.

• System 1 Integration: Data flows seamlessly into the System 1 platform, enabling automated diagnostic reporting, spectrum analysis, and long-term trend monitoring.

• Rugged Construction: The stainless-steel and IP67-rated enclosure ensures the internal electronics are protected from moisture, oil, and dust found in power plants and refineries.
