Bently Nevada 100A1000 | Proximity Probe

Product Overview

The Bently Nevada 100A1000 is a high-precision eddy current proximity probe designed for the continuous monitoring of vibration and axial position in critical rotating machinery. By utilizing advanced non-contacting sensing technology, this probe measures the minute distance between the probe tip and the rotating shaft, converting mechanical motion into accurate electrical signals when paired with a Proximitor sensor.

Technical Specifications

• Model Number: 100A1000

• Manufacturer: Bently Nevada (Baker Hughes)

• Sensing Technology: Eddy Current (Non-contacting)

• Measurement Range: Typically 0–2 mm (System Dependent)

• Linear Range: ±1 mm around calibrated gap

• Probe Tip Material: PPS (Polyphenylene Sulfide) High-Temperature Polymer

• Standard Cable Length: 1 Meter

• Mounting Thread: 3/8-24 UNF

• Operating Temperature: -35°C to +120°C

• System Compatibility: 3300 XL Proximitor Sensors and Extension Cables

• Standard Compliance: Meets API 670 requirements

Key Features and Engineering Advantages

• Non-Contact Precision: Uses eddy current fields to measure shaft motion without physical contact, eliminating wear and ensuring a long service life for the transducer system.

• Extreme Material Durability: The PPS tip is resistant to chemical erosion and thermal degradation, allowing the probe to operate reliably in oil-rich and high-heat environments.

• API 670 Compliance: Specifically designed to meet the rigorous safety and performance standards required for machinery protection systems in the oil, gas, and power industries.

• Seamless System Integration: Optimized for use with the 3300 XL series, providing linear voltage output that is highly resistant to radio frequency interference (RFI).

• Versatile Mounting: The standard 3/8-24 UNF threading allows for easy installation into existing machine housings, providing a stable platform for gap calibration.
