The Bachmann MPC265 Processor Module is a high‑performance CPU unit for M1 automation systems, engineered for deterministic real‑time control, secure communication, and robust operation in industrial environments such as energy, transportation, and manufacturing.
Specifications
Manufacturer: Bachmann electronic GmbH
Product Number: MPC265
Processor: Intel Atom quad‑core, 1.91 GHz
Memory: 4 GB DDR3 RAM
Internal Storage: 8 GB pSLC Flash
Remanent Memory: 512 kB NVRAM
Expansion: CFast slot (up to 256 GB supported)
Operating System: VxWorks with Bachmann extensions
Interfaces:
2 × Ethernet 10/100/1000 Mbit/s with IEEE 1588 synchronization
1 × RS232
1 × RS232/422/485 (software configurable)
1 × USB 2.0 host
1 × USB device (service interface)
Security: TPM 2.0 hardware module
Cooling: Fanless passive cooling
Protection: Conformal coating against dust and moisture
Operating Temperature: −30 °C to +60 °C
Storage Temperature: −40 °C to +85 °C
Features
Quad‑Core Performance: 1.91 GHz Intel Atom for demanding automation workloads
High Memory Capacity: 4 GB DDR3 RAM with 8 GB Flash storage
Secure Operation: TPM 2.0 hardware security for industrial networks
Reliable Data Retention: NVRAM ensures critical process data preservation
Flexible Networking: Dual Gigabit Ethernet with IEEE 1588 synchronization
Versatile Interfaces: RS232/422/485, USB host/device for broad connectivity
Industrial Durability: Certified for marine and harsh industrial environments
Compact Integration: Fanless design with conformal coating for long service life
