Bachmann FM212 FASTBUS Module

Description

The Bachmann FM212 FASTBUS Master Module is designed for distributed automation networks, enabling communication between the central M1 CPU and up to 15 substations. It ensures extremely low‑latency fiber‑optic data transfer over long distances with robust industrial compliance.

Specifications

• Manufacturer: Bachmann

• Part Number: FM212 (00017822‑00)

• Module Type: FASTBUS Master Module

• Interfaces: 2 × Fiber Optic (FO) ports

• Transmission Media: Plastic Optical Fiber (POF), Hard‑Clad Silica (HCS), Special HCS

• Station Distance: Up to 40 m (POF), 150 m (HCS), 180 m (Special HCS)

• Maximum Network Length: 1000 m total

• Substations Supported: Up to 15 distributed substations

• Signal Delay: Extremely low, optimized for real‑time communication

• Status Indicators: RUN/ERR LEDs, fiber type display

• Power Consumption: Approx. 5 W

• Dimensions: 130 × 25 × 150 mm

• Weight: 0.35–0.45 kg

• Operating Temperature: −30 °C to +60 °C

• Storage Temperature: −40 °C to +85 °C

• Humidity Range: 5–95% RH, non‑condensing

• Mounting: DIN rail or rack installation

• Certifications: CE, UL, RoHS, plus marine approvals (DNV, LR, ABS, BV, NK, KR, RINA)

Features

• Dual FO Interfaces: Flexible fiber‑optic connectivity for redundancy or extended reach

• Scalable Network: Supports up to 15 substations with long‑distance deployment

• Low Latency: Optimized for real‑time industrial communication

• Flexible Media: Compatible with POF, HCS, and special HCS cables

• Robust Monitoring: Clear RUN/ERR and fiber type indicators for diagnostics

• Industrial Durability: Certified for harsh environments and marine applications

• Compact Design: Easy integration into Bachmann M1 automation systems
