The Allen-Bradley 2711P-B6M3D is a high-performance operator interface terminal designed for demanding industrial automation environments. As part of the PanelView Plus series, this unit provides robust visualization and control capabilities, making it suitable for applications ranging from manufacturing assembly lines to municipal infrastructure management.
Features
5.7-inch monochrome LCD display with 320 x 240 QVGA resolution for clear process monitoring.
Dual-input interface featuring both a 40-function key physical keypad and an analog resistive touchscreen.
Integrated communication suite including RS-232, USB, Ethernet, and DH-485 ports for flexible system connectivity.
Designed for reliable operation in harsh industrial conditions with a durable enclosure rating.
Applications
Automated manufacturing and assembly lines.
Municipal water and wastewater treatment facilities.
Process control and machine monitoring systems.
Technical Specifications
Model
2711P-B6M3D
Display Type
5.7 inch Monochrome LCD
Input Voltage
24 VDC
Power Consumption
24 W
Input Current
1.0 A
Isolation Voltage
50 V continuous
Operating Temperature
0 deg C to 55 deg C
Enclosure Rating
IP54
Installation Guidelines
Ensure the unit is mounted in an enclosure that provides adequate protection and ventilation to maintain operating temperatures below 55 deg C.
Verify that the 24 VDC power supply is properly grounded and isolated to prevent electrical noise interference.
Use shielded communication cables for Ethernet and serial connections to maintain signal integrity in high-EMI environments.
Always disconnect power before installing or removing the terminal or connecting communication cables.
Ensure the gasket is properly seated during panel mounting to maintain the IP54 enclosure rating.
FAQ
What is the primary input method for this terminal?
This unit features a dual-input design, allowing operators to use either the 40-function physical keypad or the analog resistive touchscreen for system interaction.
What communication protocols are supported?
The 2711P-B6M3D supports standard industrial communication via its integrated RS-232, USB, Ethernet, and DH-485 ports.
