The 1756-IF16 Analog Input Module by Allen-Bradley is a precision 16-channel input unit designed for ControlLogix systems. It supports both voltage and current signal types with high accuracy and robust diagnostics, making it ideal for demanding industrial measurement applications.
Technical Specifications
Parameter
Value
Manufacturer
Allen-Bradley
Model Number
1756-IF16
Module Type
Analog Input Module
Product Range
ControlLogix Series
Input Channels
16
Signal Types Supported
0–10V, ±10V, 0–20mA, 4–20mA
Accuracy
±0.1% basic accuracy
Isolation
Channel-to-channel
Diagnostics
Open wire detection, over-range monitoring
Channel Filtering
Configurable (1–60Hz)
Communication
Producer/Consumer model
Keying Support
Electronic keying
Dimensions (W×H×D)
23.3 × 18.2 × 5.3 cm
Weight
0.35 kg
HS Code
8537101190
System Compatibility
PLC (ControlLogix)
Product Origin
USA
Lifecycle Status
Active
Minimum Order Quantity
1
Lead Time
In Stock
Features
Supports 16 analog inputs with flexible voltage and current ranges.
±0.1% accuracy ensures reliable signal acquisition for critical process control.
Channel-to-channel isolation minimizes cross-talk and enhances data integrity.
Built-in diagnostics improve fault detection and maintenance efficiency.
Configurable filters allow tailored response times for different applications.
Compact design optimizes rack space in ControlLogix chassis.
Seamless integration with ControlLogix architecture using Producer/Consumer communication.
