The ABB SDCS-PIN-48 3BSE004939R0002 Pulse Transformer Board is engineered for high-speed signal processing in DCS800 systems. It delivers precise pulse generation with ±0.5% modulation accuracy, ensuring stable control in demanding industrial environments.
With a wide input voltage range and adjustable output, the SDCS-PIN-48 3BSE004939R0002 supports flexible integration across various control architectures. Its rugged design and broad temperature tolerance make it ideal for harsh operating conditions.
Technical Specifications
Parameter
Value
Model Number
SDCS-PIN-48 3BSE004939R0002
Manufacturer
ABB
Product Type
Pulse Transformer Board
System
DCS800
Input Voltage Range
DC 10V to 30V
Output Voltage Range
5V to 30V (adjustable)
Peak Load Current
500 mA
Pulse Frequency Range
20 Hz to 2 kHz
PWM Accuracy
±0.5%
Operating Temperature
-20°C to +60°C
Storage Temperature
-40°C to +85°C
Dimensions (L×W×H)
27 × 10 × 2.2 cm
Weight
0.32 kg
HS Code
8537101190
Origin
Sweden
Condition
Brand New
Availability
In Stock
MOQ
1 Unit
Applications & Compatibility
The ABB SDCS-PIN-48 3BSE004939R0002 is ideal for high-speed control systems in power conversion, motor drives, and automation platforms. Its adjustable output and wide frequency range support diverse signal conditioning tasks.
This board integrates seamlessly with ABB DCS800 systems and meets international safety standards, making it suitable for global industrial deployments. Its low-maintenance design ensures long-term reliability and reduced operational costs.
