The ABB SDCS-FEX-2, also cataloged as the SDCS-FEX-2 Field Exciter Board, operates as a dedicated hardware component for field current control for DC motors within ABB DCS 500 / DCS 600 drive systems platforms. The printed circuit board assembly executes analog and digital regulation of the motor excitation loop to maintain magnetic flux stability.
Hardware Specifications
Parameter
Specification
Model
SDCS-FEX-2
Brand
ABB
Origin
Switzerland
Weight
0.32 kg
Dimensions
20.5 cm x 14 cm x 3.8 cm
Operating Temp
0 deg C to +55 deg C
Power Consumption
Powered via internal control electronics
Part Number
3ADT306311P2103
Field Voltage Range
Up to 500 VDC
Field Current Range
Up to 40 A
Coating
Conformal coating
Protection Features
Overcurrent protection, Field loss detection, Temperature monitoring
Mounting Format
Plug-in open-frame PCB module
