- ABB SDCS-CON-1 Control Board
Sale
ABB SDCS-CON-1 Control Board
No reviews
In stock!
- Part Number: SDCS-CON-1
- Brand: ABB
- Type: Control Board
- Dimensions: 116x2.5x2cm
- Country of Origin: USA
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
| Communication Protocols |
|
| Controller Design |
|
Product Description
The ABB SDCS-CON-1, also cataloged as the SDCS-CON-1 Control Board, operates as a legacy primary processing and digital control hub within early-generation DCS500 and matching industrial DC drive platforms. It forms the core computational baseline for drive regulation prior to the introduction of the later SDCS-CON-4 architecture.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model / Type Designation | SDCS-CON-1 |
| Brand | ABB |
| Lifecycle Status | Legacy / Discontinued by Manufacturer (Spare Parts Support Available) |
| Functional Core Role | Main drive execution loop, speed, and torque control regulation |
| Successor Board Profile | SDCS-CON-4 COAT (Replacement Product ID: 3ADT313900R1501) |
| Product Net Weight | 0.40 kg (0.88 lbs) |
| Gross Weight | 0.40 kg |
| Customs Tariff Code (HS Code) | 85389091 |
| UNSPSC Commodity Code | 39120000 |
| Frame Size Classification | Drive internal spare parts layout |
| Core Credit Value | 0.00 |
| Operating Temperature Range | 0 to 55 deg C internal cabinet ambient range |
Drive Core Architecture and Signal Integration
The SDCS-CON-1 processing card functions as the central logic foundation for the legacy industrial DC power converter. It executes real-time speed, torque, and armature current control loops, sending pulse-trigger commands directly across the drive backplane to the thyristor power semiconductor blocks without adding localized propagation delays. The board uses dedicated analog-to-digital channels to process tachometer feedback and armature voltage metrics natively. This micro-architecture maps internal drive tracking variables across Profinet or EtherNet/IP deterministic networks via plug-in master communication adapters, allowing rapid I/O density scaling adjustments and seamless firmware flash compatibility during live process tracking.
Frequently Asked Questions
Q: What are the primary structural differences between the legacy SDCS-CON-1 and the newer SDCS-CON-4 COAT?
A: The SDCS-CON-1 is an older-generation control board featuring standard non-coated circuit components and baseline processing speeds. The newer SDCS-CON-4 COAT board provides updated processing chips, expanded memory allocations, and a specialized conformal coating to protect surface-mount traces against conductive dust and moisture.
Q: Can an existing SDCS-CON-1 configuration file be uploaded directly into a replacement SDCS-CON-4 board?
A: No. Due to changes in processing architecture, parameter maps must be migrated systematically using compatible drive engineering software. A comprehensive firmware version check and a motor parameter self-tune routine must be executed after upgrading to the 3ADT313900R1501 hardware profile.
