ABB SD832 3BSC610065R1 switch-mode power supply

Product Overview

The ABB SD832 (Part Number: 3BSC610065R1) is a compact, high-performance switch-mode power supply designed for industrial control systems, including the S800 I/O and System 800xA. It delivers a stabilized 24 VDC at 5A and features an auto-select input for global voltage compatibility. Engineered for durability, the SD832 is G2 compliant, ensuring reliable operation in environments with corrosive atmospheric contaminants.

Technical Specifications

• Manufacturer: ABB

• Type Designation: SD832

• Product ID: 3BSC610065R1

• Input Voltage (AC): 100–120 / 200–240 VAC (Auto-select)

• Output Voltage: 24 VDC

• Output Current: 5 A

• Mounting: 35mm DIN Rail

• Compliance: G2 Corrosive Environment (ISA-S71.04), RoHS

• Dimensions (W x H x D): 32 x 124 x 117 mm

• Net Weight: 0.56 kg

• Condition: New with Original Package

• Warranty: 12 Months

• Shipping Port: Shanghai, Xiamen

Typical Applications

• ABB System 800xA: Primary power source for small-scale S800 I/O clusters and field controllers.

• Redundant Power Configurations: Can be paired with SS8xx voting units for high-availability systems where power failure is not an option.

• Process Industries: Ideal for water treatment, pulp and paper, or chemical plants requiring G2 protection against corrosion.

• Control Cabinets: Space-saving power solution for HMI panels, sensors, and remote terminal units (RTUs).
