ABB PM867K01 3BSE076355R1 Integrity Processor Kit

Product Overview

The ABB PM867K01 (3BSE076355R1) is a high-performance central processing unit for the AC 800M control system. It is specifically engineered for High Integrity applications, enabling the safe integration of business-critical process control and functional safety tasks within a single hardware unit.

Technical Specifications

• Manufacturer: ABB

• Article Number: 3BSE076355R1 (PM867K01)

• Clock Frequency: 133 MHz

• Memory: 64 MB (46.559 MB available for applications)

• Performance: 0.09 ms (per 1000 boolean operations)

• Interfaces: 2x RJ45 Ethernet (CN1, CN2), 2x RJ45 Serial (COM3, COM4)

• Redundancy: Supports CPU, CEX-Bus, and I/O redundancy

• Weight: 1200 g (including baseplate)

• Dimensions: 119 mm x 186 mm x 135 mm

Key Features

• Combined Safety & Control: Certified for IEC 61508 and TÜV, allowing standard DCS functions and safety loops to coexist without compromising integrity.

• High-Speed Logic Execution: Its 133 MHz RISC processor delivers an execution time of 0.09 ms for boolean operations, ideal for fast-acting safety shutdown systems.

• High Integrity Functionality: Safety features are activated by adding an SM812 module and using SIL-certified system software.

• Integrated Communication: Features a built-in CompactFlash interface for application storage and dual Ethernet ports for redundant control network connectivity.

• Rugged Infrastructure: Uses a specialized "slide & lock" mechanism for secure DIN rail mounting and includes unique hardware identification on each baseplate.
