ABB PM864K01 3BSE018150R1 Spare Part Kit

Product Overview

The ABB PM864K01 (3BSE018150R1) is a high-performance central processing unit kit for the AC 800M control system. It is designed to handle demanding industrial logic and communication tasks. As a legacy component, it serves primarily as a critical spare part for maintaining, repairing, or upgrading existing systems placed on the market before July 2017.

Technical Specifications

• Manufacturer: ABB

• Article Number: 3BSE018150R1 (PM864K01)

• Product Type: Central Processing Unit (CPU)

• Dimensions: 99 mm (W) x 108 mm (H) x 112.5 mm (D)

• Net Weight: 1.1 kg

• Power Connection: 4-position Power Plug (3BSC840088R4)

• Customs Tariff: 85389091

Package Components

The PM864K01 kit includes the following essential hardware:

• 1x PM864 CPU: The core processor unit.

• 1x TP830 Baseplate: 115mm width for mounting and connectivity.

• 1x TB850 CEX-bus Terminator: For terminating the communication expansion bus.

• 1x TB807 ModuleBus Terminator: For the local I/O bus.

• 1x TB852 RCU-Link Terminator: Required for single-CPU configurations.

• 1x Battery: Memory backup battery (Ref: 4943013-6).

• 1x Power Plug: 4-position connector.
