ABB PM864AK02 3BSE018164R1 Central Processing Unit

Product Overview

The ABB PM864AK02 (3BSE018164R1) is a high-capacity redundant processor kit for the AC 800M control system. Designed for mission-critical automation environments, this kit provides double the processing reliability by including two PM864A CPUs and the necessary synchronization hardware. It is a cornerstone of the System 800xA architecture, offering robust performance for complex, large-scale industrial applications.

Technical Specifications

• Manufacturer: ABB

• Article Number: 3BSE018164R1 (PM864AK02)

• Product Type: Central Unit / Redundant Processor Kit

• Redundancy: Full CPU Redundancy supported

• Dimensions: 119 mm (W) x 186 mm (H) x 135 mm (D)

• Net Weight: 2.9 kg (Complete kit)

• Power Supply: 24 V DC (via individual power plugs)

• HS Code: 853710 (Electrical Control Boards/Consoles)

Package Components

The PM864AK02 kit is a comprehensive package containing:

• 2x PM864A CPUs (High-performance processor units)

• 2x TP830 Baseplates (115mm width)

• 2x TB807 ModuleBus Terminators

• 2x Batteries for memory backup (Ref: 4943013-6)

• 2x Spare Power Plugs (Ref: 3BSC840088R4)

• 1x TK850 CEx-bus Expansion Cable

• 1x TK851 RCU-Link Cable (For CPU synchronization)
