ABB PM582-XC 1SAP340200R0201 eXtreme Conditions CPU

Product Overview

The ABB PM582-XC (1SAP340200R0201) is a ruggedized processor module from the AC500-XC (eXtreme Conditions) series. While it shares the core technical specifications of the standard PM582—including 512 kB of program memory and a fast 0.05 µs instruction processing time—the "XC" variant is specifically designed to operate where standard PLCs would fail.

Technical Specifications

• Manufacturer: ABB

• Model Number: PM582-XC

• Order Code: 1SAP340200R0201

• Processing Time: 0.00005 ms (0.05 µs) per 1000 instructions

• Memory Size: 512 kB (Program) / 928 kB (Total Data Memory)

• Data Memory Type: RAM (with non-volatile flash backup)

• Communication Interfaces:

• 2 x Serial Interfaces (configurable as RS232 or RS485)

• 1 x FieldBusPlug (FBP) Slot

• Operating Voltage: 24 V DC (Permissible range: 20.4... 28.8 V DC)

• Environmental Resilience:

• Operating Temp: -33°C to +70°C (Extended range)

• Storage Temp: -40°C to +85°C

• Protection Rating: IP20 with Conformal Coating

• Dimensions: 76 mm (H) x 67.5 mm (W) x 62 mm (D)

• Net Weight: 0.137 kg

"eXtreme Conditions" (XC) Advantages

The PM582-XC is more than just a standard PLC; it is a hardened industrial engine:

• Conformal Coating: All internal PCBs are coated to prevent short circuits and corrosion caused by condensation, salt spray, or chemical pollutants (H2S, SO2).

• Wide Thermal Window: Reliable cold-starts at -33°C and continuous operation at +70°C ensure system stability in diverse climates without the need for extensive cabinet cooling or heating.

• Vibration and Shock Resistance: Enhanced mechanical bonding of components allows the XC series to be mounted on high-vibration equipment, such as rock crushers or engine rooms.

• High Altitude Performance: Rated for reliable operation at altitudes up to 4000 meters (with slight derating), significantly higher than the 2000m standard for industrial electronics.
