ABB PM510V16 3BSE008358R1 CPU Module

Product Overview

The PM510V16 (3BSE008258R1) is a high-capacity central processing module designed for the ABB Advant Open Control System (OCS). Equipped with 16 MB of system memory via two 3BSC120004E6 SIMM modules, it offers the computational power required for large-scale industrial logic and complex process control. A unique feature of this hardware is its field-configurability.

Technical Specifications

• Manufacturer: ABB

• Model Number: PM510V16

• Part Number: 3BSE008258R1 (Exchange Part: EXC3BSE008258R1)

• Product Type: Central Processing Unit (CPU)

• Total Memory: 16 MB (via 2 x 8 MB SIMM modules, p/n 3BSC120004E6)

• Memory Scalability: Switch-selectable between 8 MB and 16 MB configurations

• System Platform: Advant OCS / Advant Controller series

• Environmental Compliance: RoHS compliant following EU Directive 2011/65/EU

• Dimensions: 477 mm (Depth) x 261 mm (Width) x 22.5 mm (Height)

• Net Weight: 0.875 kg

• Customs Tariff Number: 85389091

• Country of Origin: Sweden

System Configuration and Flexibility

The PM510V16 is engineered for flexibility in multi-generational control environments. Key functional highlights include:

• Memory Management: The inclusion of specific SIMM modules allows for easy hardware diagnostics or memory capacity adjustments via physical switches, preventing software-hardware mismatches during commissioning.

• Broad Connectivity: Compatible with the standard Advant backplane, supporting a wide array of communication and I/O interface modules.

• Marine Readiness: While the standard 3BSE008258R1 is suitable for general industrial use, it belongs to a family that includes the PM510MV16 (3BSE016240R1), which features conformal coating for vibration and humidity resistance in marine
