ABB DSQC 667 3HAC026840-001 Profibus DP Board

Product Overview

The ABB DSQC 667 (3HAC026840-001) is a specialized Profibus-DP Interface Module based on the Anybus-S technology. It serves as the primary communication link for connecting IRC5 robots to Siemens-centric or other Profibus-based industrial networks. Unlike older, larger boards, the DSQC 667 is a highly integrated module that handles the complex DPV1 protocol layer hardware-side, ensuring fast and reliable data exchange between the robot's control system and a master PLC.

Technical Specifications

• Part Number: 3HAC026840-001

• Model Designation: DSQC 667 (ABCC-DPV1)

• Interface Type: Profibus DP-V1 (Slave)

• Country of Origin: Sweden

• Customs Tariff Number: 85176200

• Net Weight: 0.028 kg

• Dimensions: 22.3 mm (D) x 56.5 mm (H) x 50.5 mm (W)

Key Features

• DPV1 Support: Supports acyclic data communication, allowing for advanced diagnostics and parameter configuration beyond simple cyclic I/O.

• High-Speed Throughput: Capable of standard Profibus baud rates up to 12 Mbps, ensuring real-time synchronization with high-speed production lines.

• Anybus Technology: Utilizes the industry-proven Anybus-S platform, known for its extreme reliability and low power consumption.

• Plug-and-Play Integration: Designed for immediate recognition by the IRC5 system when correctly configured in the RobotWare environment.

• Diagnostic LEDs: Integrated indicators provide immediate visual feedback on the health of the fieldbus connection (e.g., Network Status, Module Status).
