ABB DSQC 658 3HAC037084-001 DeviceNet Board

Product Overview

The ABB DSQC 697 (3HAC037084-001) is a high-performance DeviceNet Communication Board designed to facilitate robust networking between the IRC5 controller and external industrial devices. Functioning as a replacement for the older DSQC 658 models, this board provides the physical and logical interface required for the robot to operate as a Master or Slave on a DeviceNet network.

Technical Specifications

• Part Number: 3HAC037084-001

• Model Designation: DSQC 697

• Replaces Old IDs: 3HAC025779-001 (DSQC 658), 3HAC12817-1

• Country of Origin: Canada

• Net Weight: 0.04 kg (Ultra-lightweight)

• Dimensions: 140 mm (L) x 130 mm (W) x 10 mm (H)

• Customs Tariff Number: 85176200

Key Features

• High Integration: Merges the functionality of previous DeviceNet cards into a more reliable and energy-efficient hardware design.

• Master/Slave Versatility: Allows the robot to either lead a network of sub-devices or follow a primary factory controller (PLC).

• Shielded Communication: Features built-in protection against electromagnetic interference (EMI), common in high-voltage industrial environments.

• Optimized Performance: Engineered in Canada specifically for high-speed robotic data cycles, reducing latency in signal transmission.

• Global Support: Distributed through ABB's main hubs in Germany (Menden/Bergkamen) and China (Shanghai).
