ABB DSQC 655 3HAC025562-001 Capacitor Unit

Product Overview

The ABB DSQC 655 (3HAC025562-001) is a high-performance Capacitor Unit integrated into the IRC5 robot controller's drive system. Its primary role is to serve as an energy reservoir for the DC common bus that powers the robot's motor segments. By storing and releasing electrical energy instantaneously, the DSQC 655 smooths out voltage ripples and provides the peak current necessary during rapid acceleration or heavy lifting, preventing "DC Link Voltage Low" errors and protecting the drive electronics from power surges.

Technical Data

• Part Number: 3HAC025562-001

• Model Designation: DSQC 655

• Country of Origin: Korea, Republic of (South Korea)

• Customs Tariff Number: 85322900 (Other fixed capacitors)

• Net Weight: 0.42 kg

• Dimensions: 185 mm (L) x 65 mm (W) x 60 mm (H)

• Condition: New Spare Part

Key Features

• Energy Buffering: Stabilizes the DC bus voltage during high-dynamic robot movements, ensuring consistent motor torque.

• Peak Power Support: Supplies supplemental energy during high-load intervals, reducing the strain on the main power supply unit.

• Long-Life Industrial Grade: Built with high-spec capacitors designed to handle the frequent charge/discharge cycles typical of 6-axis robotic motion.

• Compact Integration: Slim profile allows for easy mounting within the crowded drive section of an IRC5 controller cabinet.

• Safety Discharge: Designed to work within the system's safety parameters to allow for controlled discharging when the controller is powered down.
