ABB DSQC 612 3HAC15639-1 Ethernet Communication Board

Product Overview

The ABB DSQC 612 (3HAC15639-1) is a specialized Ethernet Board designed for the ABB IRC5 robot control system. It serves as the primary hardware interface for networked communication, allowing the robot to interact with factory-level Ethernet networks (LAN), Supervisory Control and Data Acquisition (SCADA) systems, and other industrial computers. This board is essential for modern manufacturing environments that require remote monitoring, offline programming downloads, and real-time data exchange.

Technical Data

• Part Number: 3HAC15639-1

• Model Designation: DSQC 612

• Country of Origin: Malaysia

• Customs Tariff Number: 85176200

• Net Weight: 0.12 kg

• Dimensions: 180 mm (D) x 125.5 mm (H) x 21.5 mm (W)

• Condition: New Spare Part

• Storage Locations: Germany (Menden/Bergkamen), China (Shanghai)

Key Features

• High-Speed Network Integration: Provides a stable physical layer for Ethernet-based protocols, supporting rapid file transfers and high-bandwidth communication.

• Seamless IRC5 Compatibility: Engineered to integrate directly into the IRC5 computer subrack, ensuring perfect electrical and mechanical alignment with the main CPU.

• Industrial Grade Reliability: Built with components rated for continuous operation in high-temperature and high-vibration control cabinets.

• Enhanced Connectivity: Allows for the implementation of advanced software options such as PC SDK, RobotStudio Online, and FTP client/server functions.

• Global Standard Compliance: Classified under Customs Tariff 85176200 (Machines for the reception/transmission of data), meeting international industrial communication standards.
