ABB DSQC 334 3HAB5845-1 Robot Safety Interface Board

Product Overview

The ABB DSQC 334 (3HAB5845-1) is a high-reliability safety interface and brake control board designed for the ABB S4 and S4C robot controller series. It serves as the critical hardware bridge between the controller’s logic and the robot’s physical movement.

• Manufacturer: ABB

• Model Number: DSQC 334

• Part Number: 3HAB5845-1

• Product Series: S4 / S4C Robot Controllers

• Dimensions: 30 x 20 x 20 cm (Shipping dimensions)

• Net Weight: 2.0 kg

• Country of Origin: Sweden

• Customs Tariff Code: 85389091

Key Features

• Integrated Safety Logic: Directly manages the E-Stop and safeguarding circuits. If a safety breach is detected, the board facilitates an immediate halt to ensure operator and equipment protection.

• Brake Control Management: Provides the necessary electrical signals to release or engage the mechanical brakes on each robot axis. This prevents the robot arm from collapsing under its own gravity when power is removed or an emergency occurs.

• High-Speed Signal Isolation: Equipped with industrial-grade relays and optocouplers to isolate delicate control logic from high-voltage power components, preventing electrical noise interference.

• Onboard Fault Diagnostics: Features status LED indicators that allow maintenance teams to verify safety loop continuity and identify hardware failures at a glance.

• 24/7 Industrial Reliability: Manufactured to original Swedish standards, this board is engineered for continuous operation in high-stakes manufacturing environments like automotive assembly and material handling.
