ABB DSQC 327 Combination Digital Module

Product Overview

The ABB DSQC 327 (3HAB7230-1/04) is a versatile, high-density signal processing module designed for both the S4C (M97/M98) and S4C+ robot controller generations. This board serves as a consolidated interface, merging multiple input and output channels into a single hardware footprint. It plays a critical role in factory integration by bridging the communication gap between the robot's CPU and peripheral equipment like sensors, pneumatic grippers, and safety interlocks.

Technical Specifications

• Brand/Manufacturer: ABB

• Model Number: DSQC 327

• Part Number: 3HAB7230-1/04

• Product Type: Combination Digital Input/Output Module

• Controller Compatibility: ABB S4C (M97/M98) and S4C+

• Logic Level: Standard 24V DC industrial logic

• Communication Interface: Backplane-integrated serial/parallel bus

• Dimensions: 12.6 cm (D) x 12.4 cm (W) x 2.2 cm (H)

• Weight: 0.1 kg

• Country of Origin: Switzerland

Key Features

• Consolidated Hardware Footprint: Combines digital inputs and outputs on a single board, reducing the need for multiple discrete I/O modules and saving rack space.

• Dual Generation Compatibility: Engineered to work seamlessly across the S4C and the improved S4C+ controller platforms, offering flexible spare-part utility.

• High-Speed Signal Integrity: Optimized for the high-speed system bus, ensuring that peripheral feedback (like "gripper closed" sensors) is processed with minimal latency.

• Industrial 24V Logic Support: Uses standard industrial logic levels, making it directly compatible with a wide range of external sensors, relays, and PLCs.

• Robust Signal Isolation: Features integrated opto-couplers to protect the central processing unit from electrical noise and voltage spikes originating from factory floor equipment.

• Swiss Engineering: Manufactured to strict quality standards in Switzerland, ensuring long-term reliability in 24/7 manufacturing environments.
