ABB DSQC 326 3HAB2242-1 Main Computer Board

Product Overview

The ABB DSQC 326 (3HAB2242-1) is the central computational engine designed for the S4C robot controller generation (spanning the M97 and M98 eras). As the main computer board, it acts as the "brain" of the industrial robot, responsible for executing RobotWare system instructions, managing task memory, and coordinating real-time communication between peripheral I/O and drive units.

Technical Specifications

• Brand/Manufacturer: ABB

• Model Number: DSQC 326

• Part Number: 3HAB2242-1

• Product Function: Main Computer / CPU Processor Board

• Controller Generation: ABB S4C (M97, M98)

• Processor Architecture: Embedded RISC (Reduced Instruction Set Computer)

• Dimensions: 19.1 cm (H) x 13.0 cm (W) x 1.9 cm (D)

• Net Weight: 0.2 kg

• Cooling: Integrated heatsink for passive airflow cooling

• Mounting: Proprietary backplane bus connector

Key Features

• High-Speed RISC Processing: Utilizes a dedicated RISC architecture to ensure deterministic, real-time processing of motion paths and logic sequences.

• Seamless RobotWare Integration: Fully compatible with ABB’s S4C-era software, managing system parameters and user-defined RAPID programs.

• Robust Kinematic Coordination: Handles multi-axis synchronization and path planning to ensure the high-speed accuracy of IRB robots.

• Reliable Thermal Management: Features a low-profile integrated heatsink designed for the airflow characteristics of the S4C controller cabinet.

• Compact Logic Density: Incorporates CPU, memory, and bus interface logic into a single lightweight board, minimizing the hardware footprint.

• Proprietary Bus Interface: Designed for high-integrity connection to the robot's main backplane, ensuring stable data throughput and EMI resistance.
