ABB DSQC 256A 3HAB2211-1 Robot Control Board

Product Overview

The ABB DSQC 256A (3HAB2211-1/1) is a specialized control board designed for the ABB S4 and S4C robot controller generations. As a core logic component, it facilitates the processing of control signals and coordinates data flow between the main computer and the robot's drive or I/O systems.

• Brand/Manufacturer: ABB

• Model Number: DSQC 256A

• Part Number: 3HAB2211-1 / 3HAB2211-1/1

• Product Type: Control Board

• Weight: 0.2 kg

• Dimensions: 13.0 cm (H) x 1.9 cm (W) x 19.1 cm (D)

• Country of Origin: USA

Key Features

• Legacy System Optimization: Specifically engineered to match the architecture of S4 and S4C controller racks, providing a direct replacement path for aging or faulty boards.

• Compact Logic Layout: The slim 1.9 cm profile allows for high-density installation within the controller's internal card cage, maximizing cabinet space.

• Precision Signal Processing: Built with high-quality surface-mount components to ensure low-latency signal transmission and high resistance to industrial electromagnetic interference (EMI).

• Industrial Durability: Designed for 24/7 continuous operation in manufacturing environments, withstanding the heat and vibration common in robotic control cabinets.

• Easy Installation: Features a standardized edge connector for secure "plug-and-play" insertion into the backplane, reducing maintenance downtime.
